Model No.	Semi	Automatic
Material	Stainless Steel 304	Stainless Steel 304
Dimension	L1200mm×W280mm×H1000mm	L1200mm×W280mm×H1000mm
Net/Gross Weight	55kg/65kg	55kg/65kg
Passage Width	550mm	550mm
Direction	Single / Bi-directional	Single / Bi-directional
Power Supply	AC220V/110V, 50/60Hz	AC220V/110V, 50/60Hz
Operation Voltage	DC 24V 3A	DC 24V 3A
Operation Temperature	-35℃– 60℃	-35℃ – 60℃
Operation Humidity	95% (No freeze)	95% (No freeze)
Working Environment	Indoor / Outdoor	Indoor / Outdoor
Flow Rate	40 people per minute	40 people per minute
LED Indicator	Yes	Yes
Input	Dry contact/Relay	Dry contact/Relay
Communication	TCP/IP	TCP/IP
Emergency	Arm drop automatic	Arm drop automatic
Working Environment	Indoor or Outdoor	Indoor or Outdoor
Waterproof	IP67	IP67

Technical parameter:
Outline dimensions: L1200mm*W280mm*H1000mm (1400mm optional)
Material: SS304 stainless steel technology: light wire drawing type
Material thickness: 1.2mm/1.5mm/2.0mm optional
Channel width: less than 600mm
Control mode: automatic / semi-automatic / Mechanical
Way: one-way / two-way
Control software: access control attendance management system / electronic ticketing management system / consumer management system, etc.
Read / write mode: ID card / IC card /EMcard / fingerprint face recognition / QR code / static test instrument
Working environment: indoor / outdoor
Power supply: AC200V/AV110V (optional) 50HZ
Working environment temperature: -70 C -15 C
Relative humidity: less than 95%, no condensation
Pass speed: 40/ minutes
Input interface: relay signal
Normal service life: 3 million times no fault
Communication interface: RS485/TCPIP
Scalable: counting function, voice alarm function, video capture function.
